6-6-3 SEND DATA CONFIGURATION SECTION
This section contains the parameters for setting the Transmitter Portion of the BER
Meter.
Functions and parameters for the Transmitter portion of the BER Meter are as follows:
31. Send Data Output
Displays selected Output for BER Meter.
Selections include RF GENERATOR and
AUD/DATA GEN OUT. Selecting RF
GENERATOR means an RF Carrier is modulated
with the Data Signal before transmission.
Selecting AUD/DATA GEN OUT means Data
Signal is transmitted directly through the
AUDIO/DATA GEN Connector.
32. RF Field
Displays RF Generator Frequency. Selections range from 0.0000 to
1000.0000 MHz.
33. Level
Displays RF Generator output Level. Selections range from -130 to -30 dBm with
T/R Connector selected as Output (34). Selections range from -130 to -13 dBm
with AUX RF OUT Connector selected as Output (34).
34. Output
Displays Output Connector. Selections include AUX (AUX RF OUT Connector)
and T/R (T/R Connector).
35. Modulation Type
Displays Modulation Type. Selections include OFF, AM, FM and PM.
36. Modulation/Deviation Level
Displays Modulation Level. Selections range from 0.0% to 100% for AM
Modulation Type (35), 0.00 to 100 kHz for FM Modulation Type (35) and 0.00 to
10 Rad for PM Modulation Type.
37. Output Level
Displays Output Level of Data Signal.
Selections range from 0.0 to 2.5 Vp in x1
(times 1) Mode or 0 to 25 mVp in /10 (divide
by 10) Mode.
00607097
