Page #159 background image
5-14
SECTION 5
COMMON PRACTICES
5-1-7 GENERATING MICROPHONE MODULATED RF SIGNAL
This procedure configures the RF Generate Operation Screen to transmit a Microphone
Modulated RF Signal at the T/R Connector.
The Microphone is connected to the MIC/ACC Connector.
The Output Level is -50 dBm.
P
R
E
P
o Set RF Field to
Rcvr Center Frequency
.
o Set Output Level to
-50 dBm
.
o Set Output to
T/R
.
o Select Microphone (
MIC
) for Modulation Source.
o Set Modulation Type to
FM
.
o Set Deviation Range to
NAR 3
.
