SECTION 5
COMMON PRACTICES
00607224
GENERATE
1 ms/div
SCOPE
1 V
SOURCE: Scope/DVM - AC
Mod Src: EXT FM
5.00 kHz
Dev Range:
Deviation:
NAR 3
Output:
EXT
Level:
FL:
RF:
-50.0 dBm
T/R
OFF
(Rcvr Center Frequency)
UUT
MODULATION SOURCE
Generating RF Signal Using External Modulation
