A-1
APPENDIX A - USER I/O CONNECTORS AND PIN-OUT TABLE
A-1 TABLE OF I/O CONNECTORS
CONNECTOR NAME CONNECTOR TYPE SIGNAL IN/OUT SIGNAL TYPE
T/R "N" TYPE IN/OUT RF, 200 W MAX
SCOPE/DVM BNC IN Analog, 200 Vdc MAX
CAT II
DEMOD BNC OUT Audio
AUDIO/DATA GEN BNC OUT Audio
AUDIO/DATA IN BNC IN Analog, Digital
20 Vdc MAX
EXT MOD BNC IN Analog, 20 Vdc MAX
MIC/ACC 8 Pin DIN IN/OUT See Pin-Out Table
AUX RF OUT BNC OUT RF
ANTENNA TNC IN RF, 0.25 W CW MAX
AC LINE IN AC Power IN 120/240 VAC
DC IN OUT 12 Vdc, 24-30 Vdc
GPIB (IEEE-488) 24 Pin Champ IN/OUT See Pin-Out Table
RS-232 9 Pin, D IN/OUT See Pin-Out Table
EXTERNAL
REFERENCE
BNC IN 10 MHz >0 dB
Table of I/O Connectors
