6-57
SECTION 6
OPTIONS
6-13-5 HANDOFF TEST
The Handoff Test performs a series of handoffs to different Channels. The first handoff
is to the Handoff Start Channel. All other handoffs go to the next channel by adding the
Handoff Increment to the current Channel until the Handoff End Channel receives a
handoff.
To perform this test, press F2 ENABLED with cursor on Handoff Test.
Press F3 to start test. The Handoff Test cannot be selected unless the Mobile Init Test
or the Cell Init Test is selected.
28. Chan
Displays Voice
Channel which
the handoff
was made.
29. Pwr
Displays
Mobile Phone
Output Power.
Mobile Phone
is set to Power
Level selected
as Power Level
Reference in
AMPS Setup
Menu.
30. SAT
Displays SAT Frequency received from Mobile Phone.
31. SAT
Dev
Displays SAT Deviation received from Mobile Phone.
32. Err
Displays RF Frequency Error of Reverse Voice Channel.
28
29
30
31
32
8717119
RETURN
AMPS Cellular
Automatic Test
Registration
Mobile Init
Cell Init
Handoff Test
Audio Test
FINISHED
FINISHED
FINISHED
FINISHED
FINISHED
Chan
1
51
101
151
201
Pwr
22.1 dBm
22.1 dBm
21.9 dBm
22.0 dBm
22.1 dBm
5970 Hz
5970 Hz
5970 Hz
5970 Hz
5970 Hz
SAT SAT Dev
2.27 KHz
2.28 KHz
2.49 KHz
2.28 KHz
2.30 KHZ 0.05 KHz
0.05 KHz
0.05 KHz
0.05 KHz
0.05 KHz
Err
