Page #269 background image
6-94
SECTION 6
OPTIONS
6-14-10 EDACS STORE AND RECALL
The COM-120C provides the ability to store and recall EDACS system configurations.
Data is stored to one of 50 standard stored test setups under the
Type
EDACS. Press
the STORE Hard Key in any EDACS Option screen for this menu window:
1. Setup #
Displays selected Memory Location for storage of
current configuration.
2. Name
Displays optional alphanumeric label for selected
Memory Location.
3. Type
Displays the type of data currently saved in the specified setup number. Available
types to save and recall are: DUPLEX, GENERATOR, RECEIVER, GENERATOR &
RECEIVER and EDACS.
Press the RECALL Hard Key in any EDACS option screen for this menu window:
1. Setup #
Displays selected Memory Location for storage of
current configuration.
2. Name
Displays optional alphanumeric label for selected
Memory Location.
3. Type
Displays the type of data currently saved in the specified setup number. Available
types to save and recall are: DUPLEX, GENERATOR, RECEIVER, GENERATOR &
RECEIVER and EDACS.
00607091
Store setup as ...
Setup #
Name: ------
Type: EDACS
2
3
0
1
00607092
Recall setup ...
Setup #
Name: ------
Type: EDACS
2
3
0
1
