6-114
SECTION 6
OPTIONS
6-15-14 OFF-AIR MONITOR
In this mode the COM-120C becomes an off-air monitor and displays the MPT 1327
messages on screen from either a Radio Unit or Trunked Repeater Unit.
1. CCH# /
TCH#
Displays control and
traffic channel status.
The relevant cursor is
highlighted when the
COM-120C is in control or
traffic channel mode.
Softkey functions
available are dependent
upon mode.
2. PFIX/
IDENT
Identity of Radio Unit, for
use in FOLLOW mode.
3. GTC/
ACKQ
Displays statistics
summary. The cursor is
highlighted when the
COM-120C is in traffic
channel mode.
4. Repeater Monitor
Softkeys
See Appendix D.
