SECTION 6
OPTIONS
6-14-5 EDACS TRUNKING AUTOMATIC TEST RESULTS
After Automatic Testing is complete, use the softkeys to display or print the results.
Press F2 to show the first page of results. Results appear in the lower half of the
EDACS Trunking Automatic Test screen.
The following text describes the test results and their significance in order of
appearance on the screen.
If only Registration was ENABLED, only the first three rows of results are shown.
Results: Radio Test
CONTROL CHANNEL
Shows the Mobile Radio’s
Receive/ Generate RF
Frequencies used for the test
as the EDACS Control
Channel.
WORKING CHANNEL
Shows the Mobile Radio’s
Receive/ Generate RF Frequencies used for the test as the EDACS Working
Channel.
LOGICAL/GROUP ID
Shows the Mobile Radio’s Logical ID and Group ID which was acquired from the
Group Call (or Login message if Registration only) performed during the Radio
Test.
TX FREQ ERROR
Shows the RF Frequency Error of the radio transmitter kHz.
TX RF POWER
Shows the RF Power of the radio transmitter in mW (if less than 1 Watt) or Watts.
TX DATA DEV
Shows the Deviation of the Radio’s high-speed data in kHz.
SUB-AUDIBLE DEV
Shows the Deviation of the Radio sub-audible data during transmission of a Group
Call in kHz.
VOICE AUDIO DEV
Shows the Peak Deviation of transmitted microphone audio from the Radio in kHz.
0061600
Mobile Rx Mobile Tx
CONTROL CHANNEL 856.2125 811.2125
WORKING CHANNEL 857.2125 812.2125
LOGICAL/GROUP ID 1002/100
TX FREQ ERROR: -0.199 kHz
TX RF POWER: 827.4 mW
TX DATA DEV: 3.20 kHz
SUB-AUDIBLE DEV: 0.68 kHz
VOICE AUDIO DEV: 4.14 kHz
[Radio]
To Next Page
General
