6-100
SECTION 6
OPTIONS
6-15-3 CHANNEL NUMBERING
It is important the first control channel number used here is a channel defined in the
Normal Hunt table of the Radio Unit. Although an RU is instructed to MOVE to another
control channel, a channel is not acquired unless the channel is in the Normal Hunt
table. Otherwise, the RU enters a Comprehensive Hunt. This may take many minutes
before acquiring a channel and going into service.
Radio Units operating in the UK Band III sub-bands 1 and 2 use a slightly different
channel designation.
Sub-band 1
Channel No. CHAN field binary
representation
Radio Unit tx freq
1 184.5000MHz
58 1000000001 185.2125MHz
560 1111110111 191.4875MHz
Sub-band 2
Channel No. CHAN field binary
representation
Radio Unit tx freq
1 192.5000MHz
58 0000000001 193.2125MHz
560 0111110111 199.4875MHz
O
T
e
n
The COM-120C uses the binary channel number (as programmed
into the radio).
