6-34
SECTION 6
OPTIONS
6-12-8 RECEIVE TRUNKING DATA BLOCK
The Receive Trunking Data Block is used to display the Repeater parameters that are
passed to the Mobile Radio.
This information is for display only and cannot be edited.
29. Goto
Displays number of Repeater being tested.
Display of 31 indicates end of transmission
for Repeater.
30. Group
Displays ID Code specified by Group (24).
31. Repeater Status
Displays Repeater-Mobile Radio Connection
Status. CONNECT is displayed if Repeater is receiving COM-120C signal. Blank
if no signal.
32. Free
Displays Free Repeater data sent to COM-120C.
33. Home
Displays Home Repeater data sent by Repeater to COM-120C. Range is 1 to 31.
34. Area
Displays Proximity Switch setting. Displays 1 or 0.
00607241
Grou
GotAre
Hom
Fre
151
9
0
5
9
CONNEC
29
30
32
33
34
31
To Next Page
