IFR COM-120C User Manual

6-82
SECTION 6
OPTIONS
6-14-6 EDACS TRUNKING MANUAL TEST
The EDACS Trunking Manual Test consists of 2 main parts.
A Repeater Simulator for testing EDACS Radios and a Radio Simulator for testing
EDACS Repeaters.
1. Rept
Sim
Accesses the EDACS
Repeater Simulator Screen.
2. Radio
Sim
Accesses the EDACS Radio
Simulator Screen.
3. Return
Returns to the EDACS Trunking Test screen.
0061602
0
Manual Test
Repeater Simulator
Radio Simulator
RETURNRadio SimRept Sim
EDACS Trunking

IFR COM-120C Specifications

General

Resolution	1 Hz
RF Input Impedance	50 Ω
Third Order Intercept (TOI)	+10 dBm
Display Type	LCD
Display Resolution	640 x 480 pixels
RF Input Protection	1 W
Power Requirements	100-240 VAC, 50-60 Hz
Input VSWR	1.5:1
Phase Noise	-80 dBc/Hz @ 10 kHz offset
