4-47
SECTION 4
OPERATION
4-2-8 RECEIVED LEVEL METER OPERATION
The Received Level Meter for the RF Receiver measures referenced power of an RF
Signal.
Configure and operate the Received Level Meter as follows:
ZOOM
Displays full screen RF Power Meter.
o Enter RF as required.
O
T
e
n
Editing RF field affects level on RF Receive Operation Screen.
Select Cable Loss as follows:
30 dB
Selects 30 dB attenuation for Input Signal.
0 dB
Selects 0 dB attenuation for Input Signal.
Select Range as follows:
300 kHz
Selects 300 kHz IF Bandwidth Filter.
15 kHz
Selects 15 kHz IF Bandwidth Filter.
30 kHz
Selects 30 kHz IF Bandwidth Filter.
If Peak Hold Function is desired, take
meter out of Autorange and configure as
follows:
OFF/ON
Toggles Peak Hold Function ON or OFF.
RST PK
Resets Peak Hold Function.
REC LEVEL
-25 dBm-120 dBm
- 39.1 dBm
------ uV
105.0000 MHz
30 dB
ON
ON
ON
OFF
RF:
Attn:
Peak Hold:
Average:
Upper Limit:
Alarm:
Lower Limit:
ON
IF BW:
30 kHz
-70.0
-30.0
2
RECEIVE LEVEL METER
30 dB
Attn:
IF BW:
30 kHz
ON
Peak Hold:
Average:
ON
2
