IFR COM-120C User Manual

5-26
SECTION 5
COMMON PRACTICES
5-2-4 DECODING 2-TONE SEQUENTIAL FORMAT
This procedure configures the RF Receive Operation Screen to decode using the 2-Tone
Sequential format.
o Set RF Field to
Pager Center Frequency .
o Set Input to
T/R .
o Set Attenuation to
30 dB .
o Set Demodulation Type to
FM .
o Cursor to Line Field and press F6
CONFIG .
o Set AF CNTR/DECODE High-Pass Filter to
OFF .
o Set AF CNTR/DECODE Low-Pass Filter to
4 kHz .
o Press F5
EXEC .
o Press F6
RETURN .
o Cursor to Deviation Meter and press F1
ZOOM .
o Set Scp/Demod Cplg: to
AC .
o Set Range to
AUTO .
o Press F6
RETURN .
o Set Tone/Data Code to
USER .
o Press F2
DECODE .
o Observe the frequency and duration of tones received on the RECEIVED TONE
DECODING Screen.

IFR COM-120C Specifications

General

Resolution	1 Hz
RF Input Impedance	50 Ω
Third Order Intercept (TOI)	+10 dBm
Display Type	LCD
Display Resolution	640 x 480 pixels
RF Input Protection	1 W
Power Requirements	100-240 VAC, 50-60 Hz
Input VSWR	1.5:1
Phase Noise	-80 dBc/Hz @ 10 kHz offset
