4-45
SECTION 4
OPERATION
4-2-7 RF POWER METER OPERATION
The RF Power Meter for the RF Receiver measures power of an RF Signal.
Configure and operate the RF Power Meter as follows:
ZOOM
Displays full screen RF Power Meter.
o Enter RF as required.
O
T
e
n
Editing RF field affects level on RF Receive Operation Screen.
Select Cable Loss as follows:
RE-ZERO
Re-zeroes Cable Loss.
RST PK
Resets Peak Hold Function.
Select Range as follows:
MENU
Accesses menu of range selections.
If Peak Hold Function is desired, take
meter out of Autorange and configure as
follows:
OFF/ON
Toggles Peak Hold Function ON or OFF.
RST PK
Resets Peak Hold Function.
If Average Function is desired, configure
as follows:
OFF/ON
Toggles Average Function ON or OFF.
Cursor to Sample Number to enter
desired value. Range is 2 to 10.
RF POWER
200 mW0
19.2 dBm
86.1 mW
105.0000 MHz
-1.0 dB
ON
ON
ON
OFF
RF:
Cable Loss:
Peak Hold:
Average:
Upper Limit:
Alarm:
Lower Limit:
ON
Range:
200 mW
0.0200 W
0.1900 W
2
Peak Hold:
Average:
ON
ON 2
Average:
Upper Limit:
ON
ON 28.0
2
To Next Page
