5-8
SECTION 5
COMMON PRACTICES
5-1-4 GENERATING DCS CODED RF SIGNAL
This procedure configures the RF Generate Operation Screen to transmit an RF Signal
FM Modulated with a DCS Code at the T/R Connector.
The deviation is set at 0.50 kHz.
The Output Level is -50 dBm.
P
R
E
P
ο Set RF Field to Radio Center Frequency.
ο Set Output Level to -50 dBm.
ο Set Output to T/R.
ο Select DATA Generator (DATA) for Modulation Source.
ο Set Modulation Type to FM.
ο Set Deviation Level to 0.50 kHz.
ο Set Format to DCS.
ο Set Code to 114.
ο Verify radio unsquelches.
ο Turn DATA generator off.
ο Verify radio squelches.
