6-70
SECTION 6
OPTIONS
6-14 EDACS TRUNKING (OPTION 16)
The EDACS Trunking Option is used to test radios and repeaters of the EDACS trunked-
radio signaling type. EDACS Trunked Radio System is a product of GE/Ericsson. The
COM-120C EDACS Option runs in manual and automatic modes for radio and repeater
testing.
To execute EDACS Trunking Option, the selection is made from the Special Test screen.
Press the SPCL Mode Key on the front panel for this selection screen:
Press F4 EDACS or cursor to selection “4. EDACS Trunking” and press the ENTER
Hard Key to access the EDACS Trunking screen.
1. Auto
Accesses the Automatic Test
screen.
2. Manual
Accesses the Manual Test
screen.
3. Setup
Accesses the Setup Screen.
4. Return
Returns to Specials Screen.
0061601
1. Bit Error Rate
2. AMPS Cellular
3. LTR Trunking
4. EDACS Trunking
EDACS
BER
CELL
LTR
