6-45
SECTION 6
OPTIONS
6-12-16 LTR REPEATER HANDSHAKE TEST
This test verifies that the COM-120C is able to link with the Repeater and a proper
encode/decode sequence is performed. Perform these additional tests simultaneously:
RF Power, RF Error, Voice FM Deviation, Data FM Deviation, Distortion and AF
Frequency Measurement.
o Perform paragraph 6-12-6. AUDIO/DATA IN
Meters (13) are not used with this test. Set
Deviation Meter (16) to measure Voice or
Data FM Deviation as needed.
o Set Group (24) for ID Code of Mobile Radio
being simulated.
o Set In Use (23) and Home (27) to Repeater
Number.
o Set Area (28) for simulated Mobile Radio
Area switch setting.
o Connect Repeater RF Output to connector
specified by Input (20).
o Connect Mobile Radio RF Input to connector
specified by Output (6).
o Press START/STOP CONTROL Key. Verify
CONNECT is displayed for Repeater Status
(31).
00607240
Group
In UseArea
Home
Free
151
9
0
5
31 PTT
23
24
26
27
28
25
ON
00607241
Group
GotoArea
Home
Free
151
9
0
5
9 CONNECT
29
30
32
33
34
31
To Next Page
