IFR COM-120C User Manual

6-104
SECTION 6
OPTIONS
6-15-6 REPEATER SIMULATOR
In the manual Repeater Simulator mode, all editable fields are available.
1. Prefix
MPT 1327 prefix of the RU under test. Valid range is 0 to 127.
2. Ident
MPT 1327 identity of the RU under test. Valid range is 0 to 8191.
3. ESN
Electronic Serial Number of the RU under test, displayed following a successful
registration test.
4. Repeater
See, Appendix D for softkey definition.
5. Call Type
This field allows selection of the call types for COM-120C initiated calls to the RU
selected by PFIX/IDENT.
6. Status Info
Displays information messages pertaining to the current status, eg "IN TRAFFIC,"
"STATUS 27 SENT."

IFR COM-120C Specifications

General

Resolution	1 Hz
RF Input Impedance	50 Ω
Third Order Intercept (TOI)	+10 dBm
Display Type	LCD
Display Resolution	640 x 480 pixels
RF Input Protection	1 W
Power Requirements	100-240 VAC, 50-60 Hz
Input VSWR	1.5:1
Phase Noise	-80 dBc/Hz @ 10 kHz offset
