6-11 IEEE 488 (GPIB) INTERFACE (OPTION 13)
6-11-1 GENERAL
Provides parallel GPIB interface for remote operation. Refer to COM-120C TMAC
Manual for additional information on COM-120C Remote Operation and Commands.
6-11-2 CONFIGURING FOR REMOTE OPERATIONS USING GPIB
To access GPIB Setup Screen, Press SETUP MEMORY Key (21) and access “4. GPIB
SETTINGS.” Configure for GPIB Operation as follows:
o
Select Operations Mode (1). Available selections include TALK/LISTEN, TALK
ONLY and LISTEN ONLY.
o
Select GPIB Address (2). Selections range from 1 to 30.
o
Set RCI Control to
ON
.
GPIB SETUP
8717030
OPERATIONS MODE:
ADDRESS: 1
TALK/LISTEN
1
2
RETURN
3
