6-35
SECTION 6
OPTIONS
6-12-9 LTR TRUNKING AUXILIARY SETUP SCREEN
The LTR Trunking Auxiliary Setup Screen is provided to setup additional system
parameters. This screen must be configured before operating the LTR Trunking
Repeater
Simulator or the LTR Trunking Radio Simulator. Configure the LTR Trunking Auxiliary
Setup Screen as follows:
1. Radio
Ric ID
Displays Mobile Radio
Interconnect Channel
Number. Range is 1 to
250.
2. Free Rep Chan
Displays Free Repeater
Channel Number for
Free Repeater
specified on LTR
Trunking Repeater
Simulator Operation
Screen. Range is 1 to
760. If desired, the
Repeater Receive and
Transmit frequencies
are editable to 1 GHz.
3. Border Offset
Displays status of Border Offset to RF due to proximity to Canadian or Mexican
Border. Displays ENABLED or DISABLED.
4. System Sync
Displays hexadecimal code used for System Sync Code in Data Word. Default
value is 158 (Hexadecimal). Range of value is 0 to 1FF (Hexadecimal).
5. Decode Data
Displays the polarity of Decoded Data. This feature enables the LTR option to
work in any frequency band up to 1 GHz regardless of polarity.
6. Encode Data
Displays the polarity of Encoded Data. This feature enables the LTR option to
work in any frequency band up to 1 GHz regardless of polarity.
00607246
LTR Trunking
Auxiliary Setup
RADIO RIC ID
FREE REP CHAN
BORDER OFFSET
SYSTEM SYNC 158
DISABLED
2
2
RETURN
DECODE DATA NORMAL
ENCODE DATA NORMAL
150 mSec
MAX RETRIES 3
RECV IF BW
RETRY TIMEOUT
15 kHz
500 mSec
UNKEY DELAY
KEY UP DELAY
PORCH ENABLE
40 mSec
OFF
1
2
3
4
5
6
7
8
9
10
11
12
