6-13-8 CELL INIT TEST
The Cell Init (Cell Site Initiated) Test simulates a call from the Cell Site. The following
procedure performs the Cell Init Test:
o With cursor on Cell Init, press F2 ENABLED. Press F3 START to start test.
o
“Paging Mobile”, “Page Answered” and “Ringing Mobile” messages appear as Test
Set performs test.
o
“Answer Phone” prompt appears. Answer call placed to Mobile Phone.
o
“Measuring Frequency” message appears indicating Maintenance Order is sent to
the Mobile Phone for measuring Signal Tone frequency.
o
If Maintenance Order does not fail, “Press Flash Hook” prompt appears. Press
Flash Hook on Mobile Phone. “Hangup Phone” prompt appears. Hanging up Mobile
Phone completes Cell Init Test.
A Power Level Test is also performed with the Cell Init Test. Refer to paragraph
6-13-3B for Power Level Test information. After the Cell Init Test is finished, press
F2. Results to page through the Cell Init Test results.

IFR COM-120C Specifications

General

Resolution	1 Hz
RF Input Impedance	50 Ω
Third Order Intercept (TOI)	+10 dBm
Display Type	LCD
Display Resolution	640 x 480 pixels
RF Input Protection	1 W
Power Requirements	100-240 VAC, 50-60 Hz
Input VSWR	1.5:1
Phase Noise	-80 dBc/Hz @ 10 kHz offset
