4-48
SECTION 4
OPERATION
SET LVL
Once meter is configured, set reference
for meter. For greatest accuracy,
perform Set Level Function for each new
frequency.
EXEC
Used to set reference level.
ESCAPE
Exits without edit.
If Average Function is desired, configure
as follows:
OFF/ON
Toggles Average Function ON or OFF.
Cursor to Sample Number to enter
desired value. Range is 2 to 10.
If Upper Limit Function is desired,
configure as follows:
OFF/ON
Toggles Upper Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
200 W.
If Lower Limit Function is desired,
configure as follows:
OFF/ON
Toggles Lower Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
200 W.
If Alarm Function is desired, configure as
follows:
OFF/ON
Toggles Alarm Function ON or OFF. When
activated, alarm alerts over range condition.
RETURN
Returns to RF Receive Operation Screen.
ON
ON
Upper Limit:
Lower Limit:
-70.0
-30.0
ON
ON
Upper Limit:
Lower Limit:
-70.0
-30.0
Lower Limit:
Alarm:
ON
OFF
12.0
Connect a coax cable
from T/R connector
to ANT connector.
WORKING...
RF level -30.0 dBm
ADC value 408
ON
Peak Hold:
Average:
ON
2
To Next Page
