24. High-Pass Filter
Displays current High-Pass Filter setting for demodulated signal. Selections
include OFF, 300 Hz and
4 kHz.
High-Pass Filter/Low-Pass Filter combination and Bandpass Filter cannot be
active simultaneously.
25. Low-Pass Filter
Displays current Low-Pass Filter setting for demodulated signal. Selections
include OFF, 300 Hz, 4 kHz and 20 kHz.
High-Pass Filter/Low-Pass Filter combination and Bandpass Filter cannot be
active simultaneously.
26. Demod Type
Displays Demodulation Type. Selections include FM, AM and PM. Selection of
FM activates Coupling (21) and Deviation Range (22) Fields.
27. Input
Displays signal Input Connector. Selections include T/R (T/R Connector) and ANT
(ANTENNA Connector).
The following items are displayed only when AUDIO DATA IN is selected as
Receive Data Input (17):
28. Bandpass Filter
Displays current Bandpass Filter setting for
signal passed through AUDIO/DATA IN
Connector. Selections include OFF and C-
MSG (C-Message Weighted Filter).
High-Pass Filter/Low-Pass Filter combination
and Bandpass Filter cannot be active
simultaneously.
29. High-Pass Filter
Displays current High-Pass Filter setting for signal passed through AUDIO/DATA
IN Connector. Selections include OFF, 300 Hz and
4 kHz.
High-Pass Filter/Low-Pass Filter combination and Bandpass Filter cannot be
active simultaneously.
30. Low-Pass Filter
Displays current Low-Pass Filter setting for signal passed through AUDIO/DATA
IN Connector. Selections include OFF, 300 Hz, 4 kHz and 20 kHz.
High-Pass Filter/Low-Pass Filter combination and Bandpass Filter cannot be
active simultaneously.
00607096
Receive Data: AUDIO DATA IN
Data / Ber - Filter: BPF: OFF
LPF: OFF HPF: OFF
28
29
30
