4-52
SECTION 4
OPERATION
If Average Function is desired, configure
as follows:
OFF/ON
Toggles Average Function ON or OFF.
Cursor to Sample Number to enter
desired value. Range is 2 to 10.
If Upper Limit Function is desired,
configure as follows:
OFF/ON
Toggles Upper Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
20000 Hz.
If Lower Limit Function is desired,
configure as follows:
OFF/ON
Toggles Lower Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
20000 Hz.
If Alarm Function is desired, configure as
follows:
OFF/ON
Toggles Alarm Function ON or OFF.
When activated, alarm alerts over range
condition.
RETURN
Returns to RF Receive Operation
Screen.
Configure Gate Time as follows:
1 S
Selects 1 Second as Gate Time.
10 S
Selects 10 Seconds as Gate Time.
RETURN
Returns to RF Receive Operation Screen.
ON
Average:
Upper Limit:
ON
1900 Hz
2
ON
Average:
Upper Limit:
ON
1900 Hz
2
OFF
1 S
Gate Time:
Alarm:
OFF
1 S
Gate Time:
Alarm:
ON
OFF
Lower Limit:
Alarm:
100 Hz
To Next Page
