Page #178 background imageLoading...
Page #178 background image
6-3
SECTION 6
OPTIONS
4. Input Level Indicator
Displays the modulation or voltage level of the Receive Data input source. The
level indicator displays an AF Level Meter reading when the field is set for
AUDIO/DATA IN.
When the field is set for RF RECEIVER, the Demod field determines the display
(i.e., FM-Deviation Meter in kHz, AM-Modulation Meter in % or PM-Phase Meter in
Rad).
5. Bit Error Rate
Displays Bit Error Rate. Exponent changes depending on Data Pattern Size (11).
6. Receive Data Configuration Section
Contains configuration data for Receive.
7. Send Data Configuration Section
Contains configuration data for Generate Section.
