1-8
SECTION 1
INTRODUCTION
Generate Operation
The Generate Operation Spectrum Analyzer is a relative measuring device only and
available units are limited to dB. Scan widths range from 1 kHz to 100 MHz per/div and
zero scan. Available log scales are 2 and 10 dB per division. Memory functions for the
Spectrum Analyzer include store and recall of a trace, compare a stored trace to a live
trace and peak hold.
Receive Operation
The Receive Operation Spectrum Analyzer receives signals ranging from 250 kHz to
1000 MHz. Scan widths range from 1 kHz to 100 MHz per/div and zero scan. Available
log scales are 2 and 10 dB per division. Amplitude scale units are dBm, dBµV, dBmV,
dBV, dBµW and dBW. Memory functions for the Spectrum Analyzer include store and
recall of a trace, compare a stored trace to a live trace and peak hold. Input signals
can be “off the air” through the Antenna Connector or connected directly to the T/R
Connector. The Spectrum Analyzer has 0 and 30 dB attenuation available through both
connectors.
Independent
The Independent Spectrum Analyzer receives signals ranging from 250 kHz to 1000
MHz. Scan widths range from 1 kHz to 100 MHz per/div and zero scan. The log scales
are 2 and 10 dB per division. Amplitude scale units are dBm, dBµV, dBmV, dBV, dBµW
and dBW are available. Memory functions for the Spectrum Analyzer include store and
recall of a trace, compare a stored trace to a live trace and peak hold.
Input signals can be “off the air” through the Antenna Connector or connected directly to
the T/R Connector. The Spectrum Analyzer has 0 and 30 dB attenuation available
through both connectors. Additional Functions available with the Independent Spectrum
Analyzer include a Find function for finding signals above a certain level and split
screen displaying two Spectrum Analyzer screens.
