6-84
SECTION 6
OPTIONS
3. RF: (Receive)
This field shows the current RF Frequency of the EDACS Working Channel for the
Receiver side of the Repeater Simulator. This field is editable (which puts the
Working Channel in ‘Manual’ mode). Value range: 0 to 1000.0000 MHz.
4. Atten:
This field is used to set the Receiver Attenuation. Value range: 0 or 30 dB.
5. Input:
This field is used to select the Receiver’s RF Input for the Repeater Simulator to
the T/R or Antenna connector. Valid values are T/R or ANT.
6. Group ID:
This field shows the Radio’s Group ID acquired from a Group Call or Login
operation (if performed). This field is also used for the Group ID when making a
call to the Radio Under Test. This field is editable. Value range: 0 to 2047.
7. Call Type:
This field handles outgoing call processing selections Group, Individual or
System-All calls, for Radio and Repeater-initiated calls.
8. Logical ID:
This field shows the Radio’s Logical ID acquired from a Group Call or Login
operation (if performed). This field is also used for the Logical ID when making a
call to the Radio Under Test. This field is editable. Value range: 0 to 16383.
9. RF Power:
This field shows the Radio’s Transmitter RF Power in Watts (or mW). It is a
display-only field (meter) with no cursor position. Value range: 0.0 mW to
10.00 W.
10. RF Error
Freq:
This field shows the Radio’s Transmitter RF Frequency Error in kHz. It is a
display-only field (meter) with no cursor position. Value range: ±0.000 to
5.000 kHz.
11. Deviation: (Receive)
This field shows the Radio’s Transmit Deviation for Voice or Data in kHz. Voice
Deviation is designated with a ‘V’ symbol, and Data Deviation (low-frequency
data) is designated with a ‘D’ symbol. Value range: 0.00 to 10.00 kHz.
12. AF Frequency:
This field shows the Radio’s Transmitter Audio Frequency in Hz. It is a display-
only field (meter) with no cursor position. Measuring range: 300 to 4500 Hz.
