6-92
SECTION 6
OPTIONS
21. Modulation:
This field is active when the selected source is AM modulation type. This controls
the modulation of the selected source. Value range: 0.0% to 100.0%.
22. Frequency:
This field is active when the selected source, GEN1 or GEN2, is modulated. This
selects the Audio Frequency of the selected Function Generator source (sine
wave). Value range: 0.0 Hz to 20000.0 Hz.
23. Subaud
dev:
This field is active when the selected source, DATA, is modulated. This controls
the deviation of the sub-audible data used during an established call initiated from
the Radio Simulator. Value range: 0.00 to 100.0 kHz.
Should be
≤
Deviation
(20). The recommended default value is 0.70 kHz (0.35 kHz for narrow band).
24. Code:
This field is active when the selected source, DTMF, is modulated. This allows
the entry of desired DTMF digits to use for DTMF source generation.
25. Sinad:
This field is used to select a meter to read signals from the Audio/Data/SINAD
input baseband jack. The measurements appear to the right of this field. Valid
selections:
O
T
e
n
When baseband measurements are made, all receiver
measurements including the DSP data decoding are disabled due
to hardware limitations. Therefore an EDACS Call Processing
cannot be made with any baseband measurements enabled. The
Call Processing must be made first, then the baseband
measurements may be enabled during the call.
