1-15
INTRODUCTION
RECEIVER
Frequency
Range:
Resolution:
Tunable Range:
Sensitivity:
Antenna Input Protection:
Selectivity:
Adjacent Channel Rejection:
250 kHz to 1 GHz
100 Hz
Tunable from 100 Hz to 1.0 GHz
(characteristics below 250 kHz are not
specified)
2 µV (10 dB SINAD, >2 MHz, 1 kHz tone,
3.3 kHz deviation, 15 kHz IF BW,
C-Message weighted filter, 10 kHz FM
deviation meter range, 15° to 35° C),
≤ 2.5 µV otherwise
10 W CW (5 sec with alarm)
300 kHz, 15 kHz, 30 kHz
IF BW Selectivity
(3 dB) >30.0 dB Down
300 kHz ± 485 kHz
15 kHz ± 15 kHz
Demodulation Output
FM:
AM:
∅ M:
0.20 Vpk/kHz, ± 10% (10 kHz range)
0.10 Vpk/kHz, ± 10% (20 kHz range)
0.04 Vpk/kHz, ± 10% (50 kHz range)
0.02 Vpk/kHz, ± 10% (100 kHz range)
1.13 Vrms (±0.06 Vrms) (80%
modulation)
0.2 Vpk/Rad, ±10%
