1-17
SECTION 1
INTRODUCTION
FREQUENCY MODULATION METER
Range:
Resolution:
Accuracy:
Modulation Rate:
Carrier Range:
Carrier Level:
T/R Connector:
ANT Connector:
2, 5, 10, 20, 50, 100 kHz full scale
10 Hz (2, 5 and 10 kHz range)
100 Hz (20, 50 and 100 kHz ranges)
± 5% full scale, ± 50 Hz, ± 1 digit + source
residual FM (300 kHz IF BW, 1 kHz tone,
5 kHz deviation, C-Message weighted
filter)
0 to 20 kHz
250 kHz to 1 GHz (The received
frequency must be within the IF
bandpass of the COM-120C.)
0 to +53 dBm
-60 to 0 dBm
M METER
Range:
Resolution:
Accuracy:
Modulation Rate:
Carrier Range:
Carrier Level:
T/R Connector:
ANT Connector:
1, 2, 5, 10 rad peak full scale
0.01 rad (1 and 2 rad scales)
0.1 rad (5 and 10 rad scales)
± 5% of full scale ± 0.1 rad, ± 1 count +
source residual PM (300 kHz IF BW,
1 kHz tone, 1.0 rad deviation, C-Message
weighted filter)
100 Hz to 6 kHz
250 kHz to 1 GHz (The received
frequency must be within the IF
bandpass of the COM-120C.)
0 to +53 dBm
-60 to 0 dBm
