1-20
SECTION 1
INTRODUCTION
DIGITAL VOLTMETER
Ranges:
Range:
DC:
AC:
Resolution:
Accuracy:
Frequency:
Input Impedance:
50 mV to 200 V in a 1-2-5 sequence
10 mV to 200 Vdc (SCOPE/DVM input)
10 mV to 200 Vrms (SCOPE/DVM input)
150 mV to 15 Vrms (AUDIO/ DATA input)
3.5 digit
±5% full scale, ±5 mV ±1 digit
(SCOPE/DVM input)
±7% full scale, ±5 mV ±1 digit
(AUDIO/DATA input)
DC, 50 Hz to 20 kHz
1 MΩ unbalanced (SCOPE/DVM/SINAD
input)
100 kΩ , unbalanced (AUDIO/DATA input)
OSCILLOSCOPE
Bandwidth (3 dB): 50 kHz
Vertical
Ranges:
Maximum Input:
Accuracy:
Resolution:
Coupling:
10 mV to 50 V/div in a 1-2-5 sequence
200 rms
5% full scale
1% full scale, 256 data points, 8 major
divisions
DC, AC and GND
Horizontal
Ranges:
Resolution:
Accuracy:
Input Impedance:
100 µs to 200 ms/div in a 1-2-5 sequence
1% full scale, 500 data points, 10 major
divisions
1% full scale
1 MΩ , unbalanced (nominal)
