3-28
SECTION 3
COMPOSITE
8. Keyboard
The Keyboard Setup Screen accesses specific operation parameters.
9. DSP
Selftest
The DSP Selftest screen is for performing selftests and reading results. Use the
Soft Function Keys to activate the desired test. Each performed test receives a
PASS/FAIL indication.
10. PCMCIA Setup
A variety of screens appear under this setup entry depending on the type of
PCMCIA card installed.
The COM-120C PCMCIA card slot is another Input/Output Source when a PCMCIA
card is inserted.
11. Print Screen Setup
The Print Screen Setup allows the COM-120C to print to a File, RS-232, PCMCIA
card or GPIB. Drive, File, Type, Print Mode and Format are all configurable.
12. Restore Defaults
When selected, the COM-120C immediately restores the Receiver, Generator,
Duplex, screens, etc. to the original factory defaults.
