4-19
SECTION 4
OPERATION
If Upper Limit Function is desired,
configure as follows:
OFF/ON
Toggles Upper Limit Function ON or
OFF. Enter Limit Value. Range is 0.00
to 50.00 Vrms.
If Lower Limit Function is desired,
configure as follows:
OFF/ON
Toggles Lower Limit Function ON or
OFF. Enter Limit Value. Range is 0.00
to 50.00 Vrms.
If Alarm Function is desired, configure as
follows:
OFF/ON
Toggles Alarm Function ON or OFF.
When activated, alarm alerts over range
condition.
RETURN
Returns to RF Generate Operation
Screen.
Select desired units for digital readout
as follows:
Vrms
Select Vrms as units.
dBm
Select dBm as units. Range is 0 to 1000 Ω.
dB
Select dB as units. Press F3 as needed
to set current reading as Reference.
Upper Limit:
Lower Limit:
ON
ON
0.50V
1.50V
Lower Limit:
Alarm:
ON
OFF
0.50V
Lower Limit:
Alarm:
ON
OFF
0.50V
0.95 dBm
Z = 600 Ohms
