Parameter Value Description
GS2 Same_as_initial_parameter, 0, 1, 2, 3 Puts CTLE Low Frequency Gain
Shaping 2.
RF_B1 Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8 RF_B1 Setting.
RF_B1 Fix/Adaptable Fix, Adaptable RF_B1 Setting - Fix or
Adaptable options.
RF_B0 Same_as_initial_parameter, 0, 1, 2, 3, 4, 5 RF_B0 Setting.
RF_B0 Fix/Adaptable Fix, Adaptable RF_B0 Setting - Fix or
Adaptable options.
RF_A Same_as_initial_parameter, 100, 110, 120, 130, 140, 150, 160 RF_A Setting.
GAINLF Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Inputs CTLE Low Frequency
Gain.
GAINLF Fix/Adaptable Fix, Adaptable Inputs CTLE Low Frequency
Gain - Fix or Adaptable options.
CTLE LF Min Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits CTLE LF minimum.
CTLE LF Max Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits CTLE LF maximum.
GAINHF Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Inputs CTLE High Frequency
Gain.
GAINHF Fix/
Adaptable
Fix, Adaptable Inputs CTLE High Frequency
Gain - Fix or Adaptable options.
CTLE HF Min Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits CTLE HF minimum.
CTLE HF Max Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits CTLE HF maximum.
RF_P2 Same_as_initial_parameter, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1,
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
RF_P2 setting.
RF_P2 Fix/Adaptable Fix, Adaptable RF_P2 setting - Fix or
Adaptable options.
RF_P2 Min Same_as_initial_parameter, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1,
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Limits RF_P2 minimum.
RF_P2 Max Same_as_initial_parameter, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1,
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Limits RF_P2 maximum.
RF_P1 Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
RF_P1 setting.
RF_P1 Fix/Adaptable Fix, Adaptable RF_P1 setting - Fix or
Adaptable options.
RF_P1 Min Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits RF_P1 minimum.
RF_P1 Max Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Limits RF_P1 maximum.
RF_P1 Threshold Same_as_initial_parameter, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15
Controls the rate RF_P1 adapts.
RF_P0 Same_as_initial_parameter, -15, -14, -13, -12, -11, -10, -9, -8,
-7, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,
13, 14, 15
Limits RF_P0.
continued...
2. Implementing the Transceiver PHY Layer in Intel Stratix 10 Devices
UG-20056 | 2019.02.04
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
Send Feedback
40
