Parameter Value Description
GS2 Fw_default, 0, 1, 2, 3 CTLE Low Frequency Gain
Shaping 2.
RF_B1 Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8 RF_B1 Setting.
RF_B1 Fix/Adaptable Fix, Adaptable RF_B1 Setting.
RF_B0 Fw_default, 0, 1, 2, 3, 4, 5 RF_B0 Setting.
RF_B0 Fix/Adaptable Fix, Adaptable RF_B0 Setting.
RF_A Fw_default, 100, 110, 120, 130, 140, 150, 160 RF_A Setting.
GAINLF Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 CTLE Low Frequency Gain.
GAINLF Fix/Adaptable Fix, Adaptable CTLE Low Frequency Gain - Fix
or Adaptable options.
CTLE LF Min Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits CTLE LF minimum.
CTLE LF Max Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits CTLE LF maximum.
GAINHF Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Inputs CTLE High Frequency
Gain.
GAINHF Fix/
Adaptable
Fix, Adaptable Inputs CTLE High Frequency
Gain - Fix or Adaptable options.
CTLE HF Min Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits CTLE HF minimum.
CTLE HF Max Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits CTLE HF maximum.
RF_P2 Fw_default, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10
RF_P2 setting.
RF_P2 Fix/Adaptable Fix, Adaptable RF_P2 setting - Fix or
Adaptable options.
RF_P2 Min Fw_default, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10
Limits RF_P2 minimum.
RF_P2 Max Fw_default, -10, -9, -8, -7, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10
Limits RF_P2 maximum.
RF_P1 Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 RF_P1 setting.
RF_P1 Fix/Adaptable Fix, Adaptable RF_P1 setting - Fix or
Adaptable options.
RF_P1 Min Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits RF_P1 minimum.
RF_P1 Max Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Limits RF_P1 maximum.
RF_P1 Threshold Fw_default, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Controls the rate RF_P1 adapts.
RF_P0 Fw_default, -15, -14, -13, -12, -11, -10, -9, -8, -7, -6, -5, -4,
-3, -2, -1, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Limits RF_P0.
RF_P0 Fix/Adaptable Fix, Adaptable Limits RF_P0 - Fix or Adaptable
options.
RF_P0 Threshold Fw_default, -15, -14, -13, -12, -11, -10, -9, -8, -7, -6, -5, -4,
-3, -2, -1, 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Controls the rate RF_P0 adapts.
RF_B0T Fw_default, 10, 15, 20, 25, 30, 35, 40, 45, 50 Controls the rate RF_B0
adapts.
Continuous Adaptation Parameters
GS1 Same_as_initial_parameter, 0, 1, 2, 3 Puts CTLE Low Frequency Gain
Shaping 1.
continued...
2. Implementing the Transceiver PHY Layer in Intel Stratix 10 Devices
UG-20056 | 2019.02.04
Send Feedback
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
39
