Intel Stratix 10 - Dynamic Reconfiguration Parameters

Figure 29. Dynamic Reconfiguration Options
Table 21. Dynamic Reconfiguration Parameters
Parameter Value Description
Enable dynamic reconfiguration On/Off Enables the dynamic reconfiguration interface.
Share reconfiguration interface On/Off When enabled, the Native PHY presents a single Avalon-MM
(AVMM) slave interface for dynamic reconfiguration of all
channels. In this configuration, the upper [n-1:19] address bits
of the reconfiguration address bus specify the selected channel,
continued...
