Table 32. PMA Parameter Tuning for Optimal Performance
These are the tuned PMA parameter settings that result in optimal link performance across a temperature
sweep for each test configuration. An integer value means that the parameter is fixed, and "Firmware Default"
means that the parameter is adaptive.
Parameter PAM4 NRZ
56 Gbps 28 Gbps 10 Gbps
LR VSR LR VSR 25 dB/15 dB/10 dB
PMA Tuning Configuration Before Running Initial Adaptation
RF_A0 130 130 130 Firmware Default
(9)
Firmware Default
(9)
GS1 1 0 2 2
GS2 1 0 2 1
RF_B0 2 3 1 1
RF_B1 8 3 1 5
CTLE LF max 2 Firmware
Default
(9)
3 2
RF_P1_MAX 6 6 6 Firmware Default
(9)
RF_P2 Firmware
Default
(9)
Firmware
Default
(9)
0 0
RF_B0T 40 10 10 Firmware Default
(9)
PMA Tuning Configuration Before Running Continuous Adaptation
RF_B1 Firmware
Default
(9)
Firmware
Default
(9)
8 Firmware Default
(9)
Firmware Default
(9)
3.1.3.4. General PMA Tuning Guidelines
Observe these guidelines for custom data rate and channel situations.
(9)
Find the firmware default values in Table 30 on page 65.
3. Intel Stratix 10 E-Tile Transceiver PHY Architecture
UG-20056 | 2019.02.04
Send Feedback
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
73
