AC Power Supply Specifications for EX4550 Switches
Table 45 on page 85 lists the power supply specifications for an AC power supply used
in an EX4550 switch.
Table 45: AC Power Supply Specifications for an EX4550 Switch
SpecificationItem
Operating range:
•
Low-voltage line—100–120 VAC
•
High-voltage line—200–240 VAC
AC input voltage
50–60 HzAC input line frequency
•
Low-voltage line—7.8 A
•
High-voltage line—3.8 A
AC input current rating
•
Low-voltage line—650 W
•
High-voltage line—650 W
AC output power
336 WMaximum System Power Requirement for EX4550-32F switches with two
EX4550-EM-8XT expansion modules installed
1146 BTU/HourSystem Thermal Output of EX4550-32F switches with two
EX4550-EM-8XT expansion modules installed = (MaximumSystem Power
Requirement ) * 3.41
NOTE: 1 W = 3.41 BTU/Hour
403 WMaximum System Power Requirement for EX4550-32T switches with two
EX4550-EM-8XT expansion modules installed
