CHAPTER 9
Pinout Specifications
Console Port Connector Pinout Information for an EX Series Switch on page 123
Mini-USB Port Specifications for an EX4550 Switch on page 124
USB Port Specifications for an EX Series Switch on page 125
Management Port Connector Pinout Information for an EX4550 Switch on page 126
Network Port and Expansion Module Port Connector Pinout Information for EX4550
Switches on page 127
RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch on page 131
Virtual Chassis Port Connector Pinout Information for EX4550 Switches on page 131
Console Port Connector Pinout Information for an EX Series Switch
The console port on an EX Series switch is an RS-232 serial interface that uses an RJ-45
connector to connect to a console management device. The default baud rate for the
console port is 9600 baud.
Table 58 on page 123 provides the pinout information for the RJ-45 console connector.
An RJ-45 cable and an RJ-45 to DB-9 serial port adapter are supplied with the switch.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to an EX Series switch, use a
combination of the RJ-45 to DB-9 female adapter supplied with the switch
and a USB to DB-9 male adapter. You must provide the USB to DB-9 male
adapter.
Table 58: EX Series Switches Console Port Connector Pinout Information
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
123Copyright © 2015, Juniper Networks, Inc.
