NOTE: If the AC LED and the DC LED are unlit, either the AC power cord is not

installed properly or the power supply fuse has failed.

If the AC LED is lit and the DC LED is unlit, the AC power supply is installed

properly, but the power supply has an internal failure.

Documentation

AC Power Supply in EX4550 Switches on page 41•

• AC Power Supply Specifications for EX4550 Switches on page 85

• Connecting AC Power to an EX4550 Switch on page 163

DC Power Supply in EX4550 Switches

The DC power supply in EX4550 switches is a hot-insertable and hot-removable

field-replaceable unit (FRU): You can install it without powering off the switch or

disrupting the switching function.

All the EX4550 switches that are powered by DC power supplies, except the

EX4550-32F-S switches are shipped with one DC power supply pre-installed in the rear

panel of the switches. EX4550-32F-S switches are not shipped with pre-installed power

supplies; you must order them separately.

This topic describes the DC power supplies used in EX4550 switches.

The DC power supply gives an output power of 650 W. Figure 27 on page 45 shows a DC

power supply for an EX4550 switch.

NOTE: The V+ terminals are shunted internally together, as are the V-

terminals. The same polarity terminal can be wired together from the same

source to provide an additional current path in a higher power chassis. Each

power supply must be connected to a single source only.
