Table 7: LCD Panel Menu Options in EX4550 Switches
DescriptionMenu Label
In the Idle menu:
•
Press Enter to cycle through the Status LED modes, which are port status indicators:
•
ADM (administrative status)
•
DPX (duplex)
•
SPD (speed)
See “Network Port and Expansion Module Port LEDs in EX4550 Switches” on page 30 for information
about the Status LED modes.
•
Press Menu to exit the Idle menu and go to the Status menu.
IDLE
In the Status menu, press Menu to cycle through the following information:
•
VCPs status: Up or Down
Display the status of VCPs on the Virtual Chassis module installed on the front panel followed by the
status of VCPs on the Virtual Chassis module installed on the rear panel of the switch.
•
Power supply status: OK, Failed, or Absent.
•
Fan status and Temperature status.
•
Fan status: OK, Failed, or Absent
•
Temp status: OK, High, or Shutdown
•
Junos OS version for EX Series switches loaded on the switch.
•
EXIT STAT MENU?
Choose one of the following:
•
Press Enter to exit the Status menu and go to the Maintenance Menu.
•
Press Menu to display the status of the VCPs again.
You can disable the Status menu or the options in the Status menu in the LCD panel. See “Configuring the
LCD Panel on EX Series Switches (CLI Procedure)” on page 193.
STATUS
