Figure 65: Removing a 10GBASE-T Expansion Module from an
EX4550-32T Switch
g021475
Figure 66 on page 213 shows removing a QSFP+ expansion module from the front panel
of an EX4550-32T switch.
Figure 66: Removing a QSFP+ Expansion Module from an EX4550-32T
Switch
g02 1483
Related
Documentation
• Installing an Expansion Module in an EX4550 Switch on page 209
• Installing and Removing EX4550 Switch Hardware Components on page 155
• Field-Replaceable Units in EX4550 Switches on page 18
• EX4550 Switches Hardware Overview on page 3
213Copyright © 2015, Juniper Networks, Inc.
Chapter 18: Replacing Expansion Module
