Juniper EX4550 Hardware Guide

Table 5: CLI Equivalents of Terms Used in the Documentation for EX4550 Switches (continued)
Additional InformationItem in DocumentationValue (CLI)
Description
(CLI)
Hardware
Item (CLI)
Understanding Interface
Naming Conventions on EX
Series Switches
The switch does not have
actual PIC devices; see
entries for PIC 0 through PIC
2 for the equivalent item on
the switch.
n is a value in the range 0
through 2.
Abbreviated
name of the
Physical
Interface Card
(PIC)
PIC (n)
“EX4550 SwitchesHardware
Overview” on page 3
Built-in network ports on the
switch.
PIC 0One of the
following:
•
32x 1G/10G
SFP/SFP+
•
32x
100M/1G/10G
BASE-T
•
Expansion Modules in
EX4550 Switches on
page 23
•
Virtual Chassis Module in
EX4550 Switches on
page 26
The expansion module or
the Virtual Chassis module
installed in the module slot
on the front panel of the
switch.
PIC 1One of the
following:
•
8x 1G/10G
SFP/SFP+
•
8x
100M/1G/10G
BASE-T
•
2x40GE
QSFP+
•
2x 32GE
Virtual
Chassis
•
Expansion Modules in
EX4550 Switches on
page 23
•
Virtual Chassis Module in
EX4550 Switches on
page 26
The expansion module or
the Virtual Chassis module
installed in the module slot
on the rear panel of the
switch.
PIC 2One of the
following:
•
8x 1G/10G
SFP/SFP+
•
8x
100M/1G/10G
BASE-T
•
2x40GE
QSFP+
•
2x 32GE
Virtual
Chassis
“Pluggable Transceivers
Supported on EX4550
Switches” on page 93
Optical transceiversn is a value equivalent to the
number of the port in which
the transceiver is installed
Abbreviated
name of the
transceiver
Xcvr (n)
AC power supply or DC
power supply.
n has a value 0 or 1,
corresponding to the power
supply slot number.
One of the
following:
Power supply
(n)
•
AC Power Supply in
EX4550 Switches on
page 41
•
JPSU-650W
-AC-AFO CAUTION: Do not mix:
Copyright © 2015, Juniper Networks, Inc.14
EX4550 Switch Hardware Guide

Juniper EX4550 Specifications

Console Connection Settings

baud rate	9600
data bits	8
stop bits	1
