RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect
to a management device such as a PC or a laptop. If your laptop or PC does not have a
DB-9 male connector pin and you want to connect your laptop or PC to the switch, use
a combination of the RJ-45 to DB-9 female adapter supplied with the switch along with
a USB to DB-9 male adapter.
Table 64 on page 131 provides the pinout information for the RJ-45 to DB-9 serial port
adapter.
Table 64: RJ-45 to DB-9 Serial Port Adapter Pinout Information
SignalDB-9 PinSignalRJ-45 Pin
CTS8RTS1
DSR6DTR2
RXD2TXD3
GND5GND4
TXD3RXD6
DTR4DSR7
RTS7CTS8
Related
Documentation
Connecting a Switch to a Management Console on page 171•
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 187
• Connecting an EX9200 Switch to a Management Console or an Auxiliary Device
• Connecting and Configuring an EX9200 Switch (CLI Procedure)
• Connecting and Configuring an OCX1100 Switch (CLI Procedure)
Virtual Chassis Port Connector Pinout Information for EX4550 Switches
EX4550 switchesuse a 68-pin connector cableto interconnect switches to form a Virtual
Chassis.Table65 on page 132 provides connector pinout information for the Virtual Chassis
ports (VCPs).
