Juniper EX4550 Hardware Guide

CHAPTER 20
Maintaining and Replacing Fiber-Optic
Cable
•
Connecting a Fiber-Optic Cable to a Switch on page 221
•
Disconnecting a Fiber-Optic Cable from a Switch on page 222
•
Maintaining Fiber-Optic Cables in Switches on page 223
Connecting a Fiber-Optic Cable to a Switch
EX Series and OCX1100 switches support optical transceivers, which are field-replaceable
units (FRUs). You can connect fiber-optic cables to these transceivers.
Before you begin connecting a fiber-optic cable to an optical transceiver installed in a
switch, ensure that you have taken the necessary precautions for safe handling of lasers
(see “Laser and LED Safety Guidelines and Warnings for Switches” on page 273).
To connect a fiber-optic cable to an optical transceiver installed in a switch:
WARNING: Do not look directly into a fiber-optic transceiver or into the ends
of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected
to transceivers emit laser light that can damage your eyes.
1. If the fiber-optic cable connector is covered with a rubber safety cap, remove the cap.
Save the cap.
2. Remove the rubber safety cap from the optical transceiver. Save the cap.
3. Insert the cable connector into the optical transceiver (see Figure 52 on page 175).
221Copyright © 2015, Juniper Networks, Inc.

Juniper EX4550 Specifications

Console Connection Settings

baud rate	9600
data bits	8
stop bits	1
