Juniper EX4550 Hardware Guide

8. Perform initial configuration of the switch by following the instructions in “Connecting
and Configuring an EX Series Switch (CLI Procedure)” on page 187 or “Connecting and
Configuring an EX Series Switch (J-Web Procedure)” on page 190.
9. Set the switch’s management options by following the instructions:
•
Connecting a Switch to a Network for Out-of-Band Management on page 169
•
Connecting a Switch to a Management Console on page 171
•
Connecting an EX4550 Switch to a Management Console Using the Mini-USB
Type-B Console Port on page 173
Related
Documentation
Rack Requirements for EX4550 Switches on page 79•
• Cabinet Requirements for EX4550 Switches on page 80
• Clearance Requirements for Airflow and Hardware Maintenance for EX4550 Switches
on page 81
Mounting an EX4550 Switch
You can mount an EX4550 switch:
•
Flush with the rack front on two posts of a 19-in. two-post or four-post rack or cabinet
by using the mounting brackets provided with the switch.
•
Flush with the rack front on four posts of a 19-in. four-post rack or cabinet by using the
separately orderable four-post rack-mount kit.
•
In a position recessed 2 in. (5 cm) from the front of a 19-in. two-post or four-post rack
or cabinet by using the separately orderable four-post rack-mount kit.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
See the Related Documentation for detailed descriptions of the various rack or cabinet
mounting options.
Related
Documentation
Mounting an EX4550 Switch on Two Posts in a Rack or Cabinet on page 148•
• Mounting an EX4550 Switch in a Recessed Position in a Rack or Cabinet on page 155
• Mounting an EX4550 Switch on Four Posts in a Rack or Cabinet on page 151
• Connecting Earth Ground to an EX Series Switch on page 157
Mounting an EX4550 Switch on Two Posts in a Rack or Cabinet
You can mount an EX4550 switch on two posts in a 19-in. rack or cabinet (either a
two-post or a four-post rack or cabinet) by using the mounting brackets provided with
the switch. (The remainder of this topic uses rack to mean rack or cabinet.)
Copyright © 2015, Juniper Networks, Inc.148
EX4550 Switch Hardware Guide

Juniper EX4550 Specifications

Console Connection Settings

baud rate	9600
data bits	8
stop bits	1
