Page #166 background imageLoading...
Page #166 background image
If any part on the packing list is missing, contact your customer service representative or
contact Juniper customer care from within the U.S. or Canada by telephone at
1–800–638–8296. For international-dial or direct-dial options in countries without
toll-free numbers, see http://www.juniper.net/support/requesting-support.html .
Table 72 on page 144 lists the parts and their quantities in the packing list for an EX4500
switch.
Table 72: Inventory of Components Provided with an EX4500 Switch
QuantityComponent
1Switch
1Intraconnect module or Virtual Chassis module (preinstalled)
1Fan tray (preinstalled)
1 AC or DCPower supply (preinstalled)
1AC power cord appropriate for your geographical location (only for AC switch models)
1Power cord retainer clip (only for AC switch models)
•
Power supply cover panel: 1
•
Uplink module cover panels: 2
Cover panels for slots without installed components (preinstalled )
40Dust covers for ports
2Mounting brackets
20Mounting screws
4Rubber feet
1Accessory kit box
1Quick Start installation instructions
1Pub, Juniper Product ROHS and Warranty Document
1End User License Agreement
1Ethernet cable, RJ-45/RJ-45, 4-pair stranded UTP, category #5
1RJ-45 to DB-9 serial port adapter
NOTE: You must provide mounting screws that are appropriate for your rack
to mount the chassis on a rack or a cabinet.
