File System Usage
To display the file system storage details of a switch in the backup or linecard role, click
the image of that switch.
Chassis Viewer
Click the Rear View button to see the back of the chassis image. Click the Front View
button to see the front of the chassis image. In a Virtual Chassis configuration, the Rear
View button is disabled if the switch is not selected.
•
Table 29 on page 56—Describes the chassis viewer for EX2200 switches.
•
Table 30 on page 57—Describes the chassis viewer for EX2200-C switches.
•
Table 31 on page 57—Describes the chassis viewer for EX3200, EX3300, and EX4200
switches.
•
Table 32 on page 59—Describes the chassis viewer for EX4300 switches.
•
Table 33 on page 60—Describes the chassis viewer for EX4500 switches.
•
Table 34 on page 61—Describes the chassis viewer for EX4550 switches.
•
Table 35 on page 63—Describes the chassis viewer for EX6210 switches.
•
Table 36 on page 63—Describes the chassis viewer for EX8208 switches.
•
Table 37 on page 65—Describes the chassis viewer for EX8216 switches.
•
Table 38 on page 65—Describes the chassis viewer for the XRE200 External Routing
Engines.
Table 29: Chassis Viewer for EX2200 Switches
DescriptionField
Front View
In the image, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is nonoperational.
•
Gray—Interface is down and nonoperational.
Mouse over the interface (port) to view more information.
Interface status
Rear View
The management port is used to connect the switch to a management device for out-of-band
management.
Management (me0) port
The console port is used to connect the switch to a management console or to a console
server. (You might do this for initial switch configuration.)
Console port
Copyright © 2015, Juniper Networks, Inc.56
EX4550 Switch Hardware Guide

Juniper EX4550 Specifications

Console Connection Settings

baud rate	9600
data bits	8
stop bits	1
