Table 50: Optical interface Support for 10-gigabit SFP+ Transceivers in EX4550

Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-ERModel number10GBASE-ER

10 GbpsRate

LCConnector type

DualFiber count

1550 nmTransmitter wavelength

–4.7 dBmMinimum launch power

4 dBmMaximum launch power

–11.3 dBmMinimum receiver sensitivity

–1 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

40 km (24.8 miles)Distance

AvailableDOM support

YesSupport for Virtual Chassis

configuration

•

EX4550-32T-AFI, EX4550-32T-AFO,

EX4550-32T-DC-AFI, EX4550-32T-DC-AFO,

EX4550-32F-AFI, EX4550-32F-AFO,

EX4550-32F-DC-AFI, and EX4550-32F-DC-AFO

switches—Junos OS for EX Series switches, Release

12.2 or later

•

EX4550-32F-S switches—Junos OS for EX Series

switches, Release 12.3R5 or later

Software required
