Table 65: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)
Pin NamePin Number
N/CB15
N/CB16
N/CB17
N/CB18
N/CB19
N/CB20
N/CB21
GNDB22
P2RXP0B23
P2RXN0B24
GNDB25
P2RXP1B26
P2RXN1B27
GNDB28
P2RXP2B29
P2RXN2B30
GNDB31
P2RXP3B32
P2RXN3B33
GNDB34
Related
Documentation
• Planning EX4200, EX4500, and EX4550 Virtual Chassis on page 138
• Understanding EX Series Virtual Chassis Components
• Understanding EX Series Virtual Chassis Configuration
• Connecting a Virtual Chassis Cable to an EX4550 Switch on page 229
